StandarALERT™– Vibration diagnostic softwate with bearing and motor database

•          Intuitive user interface that is simple to learn and operate

•          Markers: Reference Cursor Delta, Harmonics, Sidebands, Fault Frequencies
•          Orbit, Filtered Orbit
•          Multi-level fault severity and prioritized repair recommendations improve repair planning
•          Modell-based machine analysis
•          Automated bearing fault identification without requiring bearing make and model number
•          Included 75,000 bearing asset library and 15,000 motor asset library
•          Narrow band analysis
•          Wide band analysis
•          Advanced reporting tools produce professional reports
•          Order Normalization, Automated
•          63 alarm bands per test location
•          99 test locations per machine
•          Order Tracking
•          Peak analysis and identification functions
•          Polar Phase Plot
•          Sideband Markers
•          Single Axis and Triaxial Circular Plots
•          Single Axis, Triaxial, and Double-Triax Spectral and Waveform Displays
•          Time Synchronous Averaging
•          Run-up / Coast-down plotting: Spectral Waterfall, Bode-Peak & Phase, Peak Hold
•          Setup wizards reduce set up time and improve configuration accuracy
•          Rapid automated data screening using sensitive narrow-band techniques

•          Early detection of machine faults through average+sigma relative criteria

•          Advanced reporting tools that produce professional reports
•          Machine performance determination through ALERT’s calculated process points
•          Integration of other PdM technologies, reports, documents, inspections, etc.

•          Integrated online monitoring, walk-around vibration collection and operating logs

StandardALERT^TM contains all of the manual analysis
tools found in ExpertALERT. The software automatically screens your data for alarms or exceedances in up to 63 alarm bands per test location and up to 99 test locations per machine. This software is appropriate for those on a budget or who have machines or applications that lend themselves better to manual analysis.
